JNMING Mechanical Timing Pulley Flange Bore 12mm Width 15mm High Speed

Description

Product Overview

The JNMING Mechanical Timing Pulley Flange is engineered for high‑precision power transmission in industrial machinery. Featuring a 3 mm pitch and 120 teeth, it delivers smooth, synchronized motion. Constructed from hardened steel, the flange offers excellent wear resistance and maintains dimensional stability under high‑speed conditions. Available in a range of bore diameters—from 8 mm to 25 mm—and two width options (10 mm and 15 mm), it provides flexibility for various machine configurations.

Usage

This pulley flange is widely used in milling machines, gear shapers, drilling machines, CNC engine lathes, hobbing machines, and other transmission applications. Its low friction design and high‑limit speed capability make it ideal for continuous operation in demanding environments. Whether you are upgrading a legacy system or outfitting a new production line, the JNMING flange ensures reliable torque transfer and minimal maintenance.

Why Choose Us

JNMING combines decades of engineering expertise with rigorous quality control to deliver components that meet exacting industrial standards. Each flange undergoes heat treatment and precision machining to guarantee consistent tooth geometry and bore accuracy. Our commitment to after‑sales support includes technical assistance, rapid replacement parts, and a satisfaction guarantee.

Key Features

• Precise 3 mm pitch and 120 teeth for accurate power transmission
• Multiple bore sizes and two width options to fit diverse equipment
• Hardened steel construction provides superior durability and wear resistance
• Low friction design enables high‑speed operation with reduced heat buildup
• Dedicated customer support and fast replacement parts for minimal downtime

FAQ

What bore sizes are available?

The flange is offered in bore diameters ranging from 8 mm to 25 mm, covering most standard machine requirements.

Can I use this flange with both 10 mm and 15 mm width shafts?

Yes, the product line includes both 10 mm and 15 mm width options, allowing you to select the width that matches your shaft specifications.

Is the material suitable for high‑speed applications?

Absolutely. The hardened steel material is heat‑treated to maintain strength and dimensional stability at high rotational speeds.

How do I ensure correct installation?

Align the bore with the shaft, secure with the appropriate set screw or key, and verify that the teeth engage smoothly with the mating gear or belt.

What warranty does JNMING provide?

JNMING offers a one‑year limited warranty covering manufacturing defects, along with access to technical support for installation and maintenance queries.
